Galvanized Wire Used For Armouring Size：1.5-6.0mm Zine：40g/m2~800g/m2 Packing： Coil， Spool Standard：JIS G 3547, YB/T 5294; BS EN 10244-2; ASTM A641; etc. zinc layer Any ZINC COATING Meet the requirements of "GB/T15393 steel wire galvanizing layer" and related standards.GB/T15393 and......Send Inquiry
Armored cables are made of different material conductors in a metal sleeve with an insulating material that is machined into a flexible, flexible assembly. Armored cables include armored thermocouples, armored thermal resistors, armored heaters and armored leads. They are mainly used for temperature measurement, signal transmission and special heating in chemical, metallurgical, mechanical manufacturing, power generation and scientific experiments. It is an armored thermocouple.
Galvanized Wire Used For Armouring
Packing： Coil， Spool
Standard：JIS G 3547, YB/T 5294; BS EN 10244-2; ASTM A641; etc.
The difference between different galvanized wires
Galvanized wire is divided into hot-dip galvanizing and cold-galvanizing (electro-galvanizing). The price of hot-dip galvanizing is the highest, and the price of electro-galvanizing is low. Hot-dip galvanizing is not easy to rust, and electro-galvanizing is easy to rust. This is the easiest way to distinguish. Hot-dip galvanizing is immersion plating in hot melted zinc bath. The production speed is fast, the coating is thick but uneven, and the market allows a minimum thickness of 45 microns and a maximum of 300 microns or more. Cold galvanizing is the gradual plating of zinc on the surface of the metal in the electroplating tank. The production speed is slow, the coating is uniform, the thickness is thin, usually only 3-15 microns, the appearance is bright, the corrosion resistance is poor. It will rust in several months.
